Dimensions
Overall Length 276.2 in. (1,935 mm)
Seat Height, Laden 330.5 in. (775 mm)
Seat Height, Unladen 31.9 in. (810 mm)
Overall Width without mirrors428.1 in. (714 mm)
Ground Clearance, Unladen24.35 in. (110 mm)
Rake (Steering Head Angle) at Ride Height (degrees) 21
Fork Angle at Ride Height (degrees) 21
Trail at Ride Height 3.3 in. (84 mm)
Wheelbase, Unladen 52 in. (1,321 mm)
Fuel Capacity, Total 3.82 gal. (14.5 l)
Fuel Capacity 0.75 gal. (2.8 l)
Oil Capacity 52.5 qt. (2.4 l)
Dry Weight 395 lb. (179 kg)
Gross Vehicle Weight Rating 850 lb. (386 kg)
Load Carrying Capacity 379 lb. (172 kg)
Powertrain
Engine Thunderstorm 1203 air/oil/fan-cooled, 4-stroke, 45 degree V-twin
Displacement 73.4 cu in (1,203 cc)
Bore 3.5 in. (88.9 mm)
Stroke 3.812 in. (96.82 mm)
Peak Torque per SAE J607, North America 84 ft-lb (114 Nm)
Peak Torque RPM per SAE J607, North America 6,000
Peak Horsepower per SAE J607, North America 103 hp (77 kW)
Peak Horsepower RPM per SAE J607, North America 6,800
Compression Ratio 10.0:1
Mileage per US EPA Urban Trace, CITY6
48 mpg (4.9 l/100 km)
Mileage per US EPA HIGHWAY Fuel Economy Test6
65 mpg (3.6 l/100 km)
Intake Zero-resistance airbox
DriveTrain
Primary Drive Type Chain
Primary Drive Ratio 1.500 (57/38)
Secondary Drive Type7
Constant path, 14mm pitch aramid reinforced Hibrex(R) belt with Flexten(R) Plus technology.
Secondary Drive Member Pitch Length (# of Teeth or # of Links) 128
Secondary Drive Ratio 2.407 (65/27)
Transmission type 5-speed, Helical gear design
Transmission Ratio, 1st 2.648
Transmission Ratio, 2nd 1.892
Transmission Ratio, 3rd 1.407
Transmission Ratio, 4th 1.166
Transmission Ratio, 5th 1
Transmission Ratio, 6th
Chassis
Front Brake ZTL-2 (tm) Braking System
Front Rotor and Caliper Configuration 8-piston, fixed caliper. Single-sided, inside-out, floating rotor.
Front Rotor Size, OD 14.77 in. (375 mm)
Number of Front Brake Rotors 1
Rear Rotor and Caliper Configuration Single-piston, floating caliper. Fixed rotor.
Rear Brake
Rear Rotor Size, OD 9.45 in. (240 mm)
Rear Suspension Type and Configuration Fully adjustable (adjustable compression damping, rebound damping and spring preload), coil-over monoshock with remote, underseat reservoir.
Front Suspension Type and Configuration Fully adjustable (adjustable compression damping, rebound damping and spring preload) inverted forks.
Front Fork Slider Tube Diameter 1.69 in. (42.9 mm)
Fork Lock Availability (true or false) True
Suspension Travel, Front Wheel, Along Fork Line 4.72 in. (120 mm)
Suspension Travel, Rear Wheel, Vertical 5.06 in. (129 mm)
Lean Angle at Full Suspension Compression, Soft Contact, Left (degrees)8
47°
Lean Angle at Full Suspension Compression, Soft Contact, Right (degrees)8
47°
Lean Angle at Full Suspension Compression, Hard Contact, Left (degrees)8
48°
Lean Angle at Full Suspension Compression, Hard Contact, Right (degrees)8
50°
Frame Aluminum frame with Uniplanar Powertrain vibration isolation system - FUEL IN FRAME
Swingarm Description Cast aluminum swingarm with detachable brace. OIL IN SWINGARM.
Wheels and Tires
Tire Brand and Model, Front Pirelli Corsa III
Tire Brand and Model, Rear Pirelli Corsa III
Tire Size Designator, Front 120/70 ZR-17
Tire Size Designator, Rear 180/55 ZR-17
Wheel Type, Front 6-spoke, ZTL, cast aluminum front wheel.
Wheel Type, Rear 6-spoke, cast-aluminum rear wheel.
Wheel Size, Front (width x dia) (in) 3.5x17
Wheel Size, Rear (width x dia) (in) 5.5x17
Electrical
Battery Type and Specifications Sealed Lead Acid, maintenance-free, 12-volt, 12 amp-hour (per Battery Council International rating), 200 cca.
Charging System Specifications 30-amp max permanent magnet single-phase alternator with solid-state regulator (405 watts@3,000 rpm, 405 watts peak)
Starter System Specifications 1.2 kW electric with solenoid shift starter motor engagement
Headlamp Type and Wattages (high, low and position lamp) Twin-projector beam (H3). 55-watt low beam, 55-watt high beam. 3-watt position lamp (EUR, ENG, JPN, AUS).
Tail Light Wattages (stop and running) .55W for tail light, 5W for stop light
Turn Signal Lights Type (manual or self-canceling) and Wattage Manual canceling, 10w.
License Plate Lamp Wattage 5w
Miscellaneous
Windscreen or Flyscreen
U.S. MSRP
Sunfire Yellow $10,299
Midnight Black $10,299
Color Options
Midnight Black, Racing Red, Arctic White/Black
