Dimensions
Overall Length2 80.3 in. (2,040 mm)
Seat Height, Laden3 30.5 in. (775 mm)
Seat Height, Unladen 31.9 in. (810 mm)
Overall Width without mirrors4 28.2 in. (716 mm)
Ground Clearance, Unladen2 4.92 in. (125 mm)
Rake (Steering Head Angle) at Ride Height (degrees) 21
Fork Angle at Ride Height (degrees) 21
Trail at Ride Height 3.3 in. (84 mm)
Wheelbase, Unladen 54.1 in. (1,374 mm)
Fuel Capacity, Total 5.3 gal. (20.1 l)
Fuel Capacity 0.8 gal. (3 l)
Oil Capacity5 3.3 qt. (3.1 l)
Dry Weight 375 lb. (170 kg)
Gross Vehicle Weight Rating 850 lb. (386 kg)
Load Carrying Capacity 390 lb. (177 kg)
Powertrain
Engine Helicon, Liquid-cooled, 4-stroke, 72 V-Twin
Displacement 68.7 cu in (1,126 cc)
Bore 4.055 in. (103 mm)
Stroke 2.658 in. (67.51 mm)
Peak Torque per SAE J607, North America 82 ft-lb (111 Nm)
Peak Torque RPM per SAE J607, North America 8,000
Peak Horsepower per SAE J607, North America 146 hp (109 kW)
Peak Horsepower RPM per SAE J607, North America 9,800
Compression Ratio 12.3:1
Mileage per US EPA Urban Trace, CITY6 39 mpg (6 l/100 km)
Mileage per US EPA HIGHWAY Fuel Economy Test6 53 mpg (4.4 l/100 km)
Intake Zero-resisitance airbox, Pressurized RAM air intake
DriveTrain
Primary Drive Type Helical gear
Primary Drive Ratio 1.806:1 (65/36)
Secondary Drive Type7 Belt
Secondary Drive Member Pitch Length (# of Teeth or # of Links) 145 tooth belt, 14mm pitch
Secondary Drive Ratio 2.593:1 (70/27)
Transmission type 6-speed, straight cut gears
Transmission Ratio, 1st 2.462
Transmission Ratio, 2nd 1.75
Transmission Ratio, 3rd 1.381
Transmission Ratio, 4th 1.174
Transmission Ratio, 5th 1.042
Transmission Ratio, 6th 0.96
Chassis
Front Brake ZTL-2 braking system
Front Rotor and Caliper Configuration 8-piston ZTL2 front caliper from Nissin
Front Rotor Size, OD 14.76 in. (375 mm)
Number of Front Brake Rotors 1
Rear Brake Two-piston, direct mount caliper, 240mm, stainless steel, fixed rotor
Rear Rotor and Caliper Configuration Same rotor as XB. Rear caliper is new solid mounted 2-piston design from Hayes
Rear Rotor Size, OD 9.45 in. (240 mm)
Rear Suspension Type and Configuration Fully adjustable (adjustable compression damping, rebound damping and spring preload), coil-over monoshock with attached reservoir.
Front Suspension Type and Configuration Fully adjustable (adjustable compression damping, rebound damping and spring preload) inverted forks.
Front Fork Slider Tube Diameter 1.85 in. (47 mm)
Fork Lock Availability (true or false) True
Suspension Travel, Front Wheel, Along Fork Line 4.72 in. (120 mm)
Suspension Travel, Rear Wheel, Vertical 5 in. (127 mm)
Lean Angle at Full Suspension Compression, Soft Contact, Left (degrees)8
48°
Lean Angle at Full Suspension Compression, Soft Contact, Right (degrees)8
48°
Lean Angle at Full Suspension Compression, Hard Contact, Left (degrees)8
50°
Lean Angle at Full Suspension Compression, Hard Contact, Right (degrees)8
50°
Frame Aluminum, fuel in frame, IRC or Intuitive Response Chassis
Swingarm Description A new cast- aluminum swing arm
Wheels and Tires
Tire Brand and Model, Front Pirelli Corsa III
Tire Brand and Model, Rear Pirelli Corsa III
Tire Size Designator, Front 120/70 ZR-17
Tire Size Designator, Rear 180/55 ZR-17
Wheel Type, Front 6-spoke, ZTL cast aluminum
Wheel Type, Rear 6-spoke, cast aluminum
Wheel Size, Front (width x dia) (in) 3.5 in x 17 in
Wheel Size, Rear (width x dia) (in) 5.5 in x 17 in
Electrical
Battery Type and Specifications Sealed Lead Acid, maintenance-free, 12-volt, 12 amp-hour (per Battery Council International rating), 200 cca.
Charging System Specifications 37-amp, permanent magnet, three-phase alternator with solid-state regulator (520W peak power)
Starter System Specifications Starter motor 900W, starter drive (gears) and one way clutch.
Headlamp Type and Wattages (high, low and position lamp) Low beam - 2 bulbs at 35 Watts each (70W) , High beam is the low beam bulbs plus 2 more bulbs at 35 W each (140w), poistion indicators are on at all times - 2 bulbs at 5w each (80W and 150W).
Tail Light Wattages (stop and running) .55W for tail light, 5W for stop light
Turn Signal Lights Type (manual or self-canceling) and Wattage Manual cancelling, Front = non-serviceable LED's. 3W (per side), Rear = replaceable bulbs, 10W (per side).
License Plate Lamp Wattage 5W
Miscellaneous
Windscreen or Flyscreen Clear windscreen
Warranty Term9 2-years
Colors/Finishes/Graphics
Body Work (molded in color) Midnight Black, Racing Red, Acrtic White
Frame Phantom Metallic
Wheels Designer Black for all models
Color Options
Midnight Black, Racing Red, Arctic White
U.S. MSRP
Midnight Black $12,499
Racing Red $12,499
Arctic White $12,499
